Horizontal Graphite Powder 432L Vacuum Induction Heating Carbon Fiber Graphitizing Furnace

1.0 set
MOQ
Horizontal Graphite Powder 432L Vacuum Induction Heating Carbon Fiber Graphitizing Furnace
Caracteristicas Galería Descripción de producto Pida una cita
Caracteristicas
Especificaciones
Condition: New
Type: Resistance Furnace
Usage: vacuum quenching furnace
Video outgoing-inspection: Provided
Machinery Test Report: Provided
Marketing Type: Ordinary Product
Warranty of core components: 1 Year
Core Components: PLC
Voltage: 380V
Dimension(L*W*H): Custom Made
Weight (T): 2 T
Power (kW): 200
Warranty: 1 Year
Key Selling Points: Famous brand PLC
Applicable Industries: graphite powder
Showroom Location: None
After-sales Service Provided: Engineers available to service machinery overseas
Product Name: vacuum induction heating carbon fiber graphitization furnace
Model no.: NTI-SML-432W
Maximum temperature: 3000 degree celsius
Power: 350KW
Input voltage: 380v
Degreasing atmosphere: nitrogen
Working area: 520x520x1600mm
Max. capacity: 432L
Application: graphite powder
After Warranty Service: Field maintenance and repair service
Local Service Location: None
Certificación: CE and ISO
Información básica
Certificación: CE and ISO
Model Number: NTI-SML-432W
Pago y Envío Términos
Packaging Details: standard export packing
Supply Ability: 100 Set/Sets per Month 432L horizontal vacum induction heating carbon fiber graphitizat
Descripción de producto

432L PID programmable horizontal vacum induction heating graphitization furnace

1. Application of carbon fiber graphitization furnace:

The equipment mainly used in the HT heating treatment on carbon material, carbon fiber, negative electrode materials, graphite powder, contacting terminal material and such related material.

2.Configuration of carbon fiber graphitization furnace:

380V±10%,50Hz/60Hz 3 phase 5 wire

One control cabinet to one furnace and optional for one to two type or one to four type.

3.Technology parameter of carbon fiber graphitization furnace:

Model Parameter

Lab usage

Production usage

NTI-SML-54W

NTI-SML-98W

NTI-SML-182W

NTI-SML-432W

NTI-SML-576W

NTI-SML-1280W

Working size

mm

300×300×600

350×350×800

450×450×900

520×520×1600

600×600×1600

800×800×2000

Heating type

/

IF induction heating

Control type

/

Thyristor control or IGBT control ( optional )

HT zone capacity

L

54

98

182

432

576

1280

Loading weight

g

HT zone capacity × density (g/cm³)×1000 Remark:1L=1000cm³

Ultimate vacuum

Pa

20

IF power

Kw

150

200

250

350

500

700

Max. working temperature

℃

3000

3000

3000

2900

2900

2900

Usual working temperature

℃

2800

2800

2800

2800

2800

2800

Temperature unifomity

℃

±10

±10

±10

±10

±15

±15

Working environment

/

Vacuum or Ar, N2 atmosphere protection( micro positive pressure)

Production procedure

Raw material suitable for graphitization furnace heating

Company Information

We are real and professional OEM of industry furnace over 10 years who has 10 staff of designer and technican experienced for years,

Main manufacturing products: Graphitization furnace, carbonization furnace,

laboratory furnace,sintering furnace, melting furnace, quenching equipment, hardening equipment,

anneal equipment and tempering equipment.

IF heating device,ultra audio induction heating equipment,

IF diathermy, hardening, welding equipment,

IF bending pipe machine, cooling tower,

graphite crucible, hard composite carbon felt

and such related industry products.

We have lots of famous clients from the world like Kolon in Korea, USI in Taiwan,

Jiangxi Zicheng in China, and Joinset in Korea and so on, as the below pictures showing.

Honor of qualification

Packaging & Shipping
Our Services

1.Special size and requirement furnace can be customized.

2.The using method and operation and related knowledge taught by our engineer before shipment.

3.Engineers available to service machinery overseas after-sales service provided.

4.Payment Terms: L/C.T T, Western union.

5.Price terms: FOB Shanghai Port, China

6.Transport way: by sea, we have good forwarders, super service and price !

7.Delvery time: Estimated time of delivery is 60 days after confirming to receive the deposit payment.

8.1 year of warranty.
