Caracteristicas Galería Descripción de producto Pida una cita

Caracteristicas

Especificaciones

Condition: New

Type: Resistance Furnace, Frit furnace

Usage: Melting Furnace, Education

Voltage: 380V

Dimension(L*W*H): 170*220*360mm

Weight (T): 0.2 T

Power (kW): 2000

Warranty: 1 Year

Key Selling Points: Accurate temperature control

Applicable Industries: Machinery Repair Shops, Manufacturing Plant

Showroom Location: None

After-sales Service Provided: Engineers available to service machinery overseas, Online support

Application: Heat Treatment

Max temperature: 2200 â„ƒ

Working temperature: 800-2200 â„ƒ

Temperature control: PID Auto Control

Heating Rate: 1-40 â„ƒ/min

key words: furnace for metal melting

Furnace temperature uniformity: +-5C

After Warranty Service: Video technical support, Online support

Local ServiceÂ Location: None

Certificación: CE ISO

Información básica

Certificación: CE ISO

Pago y Envío Términos

Packaging Details: Our furnace is filled with polyfoam and plastic film inside, while standard foreign trading wooden/paper box out side, the double packages could protect the heat treatment furnace away from the damage during the transport way delivery

Supply Ability: 100 Set/Sets per Year

Descripción de producto

High temperature 2200.C energy saving frit furnace for metal melting

Product Show

Product Description

Main technical parameter

Project	Index value
Rated voltage	380V
Heating rate	≤1-40 ℃ / min (user-friendly adjustable)
Temperature control accuracy	± 1 ℃
Temperature control method	PID regulation, microcomputer control, programmable temperature curve, without caretaker (automatic heating, insulation, cooling)
Double circuit protection	Over-temperature, overpressure, superfluidity, broken even, power failure and so on
Thermocouple type	B type / S type
Heating element	Imported high-quality silicon molybdenum rods / high-quality silicon carbon rod / high-quality resistance wire
Furnace material	Made of imported composite alumina fiber, good insulation performance, high temperature resistance and thermal shock resistance.

Lifting structure	Automatic screw screw up and down, smooth without vibration
Loading and material flow method	Top loading, bottom flow
Shell surface temperature	≤35 ℃
Temperature category	800 ° C 1000 ° C 1200 ° C 1400 ° C 1600 ° C 1700 ° C 1800 ° C

Application

Equipment widely used in universities, research institutes, industrial and mining enterprises such as powder, military, electronics, metallurgy, medicine, ceramics, glass, machinery, new material development, special materials, refractory materials, building materials, chemicals, metal sintering and metal heat treatment Experiment and production.

Technical characteristics

1.LYL-18RK series lifting frit furnace introduced advanced technology, independent research and development of energy-saving, environmental protection, new electric furnace, with advanced and reasonable structure, nice appearance, high-quality cold-rolled steel shell, the advanced CNC machining, luxury, beautiful Of the two-color imported epoxy powder electrostatic spray process, processed, high temperature, corrosion-resistant, the use of high-quality heating elements, double furnace shell with air-cooled system, can quickly cool the furnace temperature equilibrium, the furnace Surface temperature is low, fast heating and lowering speed, energy saving and so on. Furnace imported composite alumina fiber material built by the numerical control process, thermal shock resistance, good corrosion resistance, no collapse, no crystallization, no residue, no pollution, long service life. The control system adopts microcomputer artificial intelligence adjustment technology, with PID regulation, automatic control, self-tuning function, multi-section programming, and can be programmed a variety of heating, insulation, cooling program, high temperature control accuracy; integrated module SCR control, phase shift Trigger, protect the system: the use of independent over-temperature protection, over-voltage, ultra-current, leakage, short circuit protection. High degree of automation, the indicators reached the advanced level.

2.Honors: ISO9001: 2008, AAA business, CE certification

Furnace size

Crucible volume (L)	Voltage (V)	Power (kw)	Temperature control accuracy
0.9	220	4	± 1 ℃
1.6	380	10	± 1 ℃
3	380	12	± 1 ℃
5	380	15	± 1 ℃
15	380	18	± 1 ℃
30	380	25	± 1 ℃

Crucible volume can be customized according to customer requirements!

List of selectable accessories
Separate control cabinet	Touch screen instrument	Remote auxiliary module
Observation window	Air-bleed hole and chimneys	Heat fan
Crucible	Door plugging	Hearth plate
Alundum tube	Quartz tube	Vacuum pump

Production Flow

Main Products

Company Information

Luoyang Liyu Kiln Co., Ltd. is a large electric furnace manufacturing base integrating R&D, production, sales, and service. Base on professional technology and manufacturing team with over 20 years of manufacturing experience, design and manufacture of various sizes and models, a variety of high-precision electric furnace and kiln for customer according to the user requirements.

Our products mainly include high temperature muffle furnace, frit furnace, vacuum atmosphere furnace, tube furnace, box furnace and vertical furnace, etc. These products are widely used in universities, research institutes, industrial and mining enterprises for experiment and production of powder, military, electronics, metallurgy, medicine, ceramics, glass, machinery, new material development, special materials, refractory materials, building materials, chemicals, metal sintering and metal heat treatment.

We continually develop the new products, and have developed a series of energy-saving JNL furnace, furnace products with more excellent conditions of fast heating, high energy, high precision, high stability, good thermal insulation performance, full microcomputer control, programmable automatic warming, cooling, heat preservation, furnace surface temperature near room temperature etc.

In recent years, Liyu has passed ISO 9001:2008 quality management system certification in 2015, and in product safety, we passed the CE certification.

Sincerely welcome new and old customers to visit and negotiate.

Our Services

Packaging & Shipping

FAQ

Q: Can I use our country's plug?

A: Yes, we can provide following standard plugs in different countries.

Q: Usually I only need 900℃ to conduct my experiment, can I have a furnace with max temperature of 1000℃?

A: Yes, we can custom-made the furnace according to your need.

Q: How about the temperature/time control?

A: the furnace's temperature and time is controlled by PID touch panel,it is a programmable control type.Easy to operate.

Q: How about the delivery period?

A: The delivery period is depends on the order quantity, in ordinary we have 1~3 sets in stock.It can be delivery within 10 working days.
